Standard products(4-60W)-Flicker

36-48W 600mA Led Constant Current Driver

Specification
Features

Model: HAD048CXI
Input voltage: 85-265v AC
AC frequency: 50/60Hz
Output frequency: >35K Hz
Output voltage: 36-72V
Output current: 600mA
Output Power: 36-48w
Power Factor: 0.98
Efficiency: 89%
Size: 103*30*18mm
Warranty: 3 Years

CE ROSH FCC TUV UL
Stable performance
Isolated circuit
High PF
Constant current design
Working temperature: -35~+60 ℃
Storage temperature: -40~+80 ℃
Protections: Short Circuit/Over Voltage/Over termperature
Scope of application: ceiling light、spot light、panel light,PRA light etc

Download Data Sheet

Description

This is a 48W 600mA constant current led driver power supply, high pf, isolated circuit, stable performance. Output voltage 36-72V, output current 600mA, efficiency 89%, applicable for ceiling light, panel light, downlight etc.

Application

constant current led driver 600mA ceiling light led power supply 600mA corridor light

led-driver-48w-600ma-for-downlight

led driver 48W 600mA for downlight led power supply 48W for panel light

Series

CXN series--Input 85-265V,High PF,Flicker,Non-isolation

50W-HZD050CXN

CXI series--Input 85~265V,High PF,Flicker,Isolation

7W-HZD007CXI-C	9W-HAD009CXI-A	7~12W-HZD012CXI-C	18W-HZD018CXI	20W-HZD020CXI
21W-HAD021CXI-F	21W-HAD021CXI-G	24W-HZD024CXI-C	30W-HAD030CXI	8~30W-HZD030CXI
36W-HZD036CXI	36W-HZD036CXI-C	36~48W-HZD048CXI-B	36~48W-HZD048CXI	36~48W-HAD048CXI
60W-HZD060CXI-C	80W-HZD072CXI
